High Pressure Water Flow Meter Sizing for Water Jet Cutting and Desalination Skids
Quick Answer: For high pressure water flow meter sizing, send pressure, temperature, pipe size, and flow range first. Silver Instruments supplies rugged electromagnetic and Coriolis flow meters for water jet cutting skids and seawater desalination skids in Southeast Asia, the Middle East, and South America. Most skid builders need a DN15 to DN100 sensor with 4-20 mA HART and pressure ratings from PN40 to PN100.
Start With Real Operating Conditions
High pressure water flow meter sizing fails when people copy a pipe size without checking pressure and velocity. A water jet cutting pump may draw 3 m³/h at 5 bar from a city water line, but the same skid may recycle 40 L/min at 180 bar on the return side. Those two points need different sensor bodies, liners, and signal wiring.
We have seen this on customer sites many times. A customer in Vietnam asked for a DN50 electromagnetic flow meter for a water jet pump feed line. The line inside the skid was only DN32. The larger meter could not reach the minimum velocity, and the reading was unstable at low flow.
So start with five numbers. Pressure in bar. Temperature in °C. Pipe size in DN. Flow range in m³/h or kg/h. Water conductivity in µS/cm if you know it. These numbers decide whether you need an electromagnetic flow meter, a Coriolis mass flow meter, or an ultrasonic flow meter.
Water Jet Cutting Flow Meter Selection
Water jet cutting systems normally use filtered municipal water or softened water. Typical conductivity is 200 to 800 µS/cm. That is enough for an electromagnetic flow meter. We recommend a flanged or clamp style DN15 to DN50 electromagnetic flow meter on the low pressure feed line before the intensifier pump. Pressure rating PN16 or PN40 covers most inlet lines, but some boost pumps push the feed to 15 bar or 20 bar. Check the peak pressure before ordering.
On the high pressure return or recycling circuit, keep the flow meter away from the nozzle if the line exceeds 100 bar. Standard electromagnetic flow meters with PN100 flanges can handle 100 bar at room temperature. Above that, use a Coriolis mass flow meter with a high pressure body, or move the measurement point to a lower pressure branch. For a cutting table that uses abrasive water, select a sensor with a PTFE liner and 316L electrodes. Abrasive particles may not reach the feed line, but rust and fine sand sometimes do.
Here is the thing. Many skid builders do not need a meter at 3000 bar. They need a reliable meter at the pump inlet or in the cooling water loop. Put the sensor there and you get stable readings without paying for exotic high pressure seals.
Desalination Skid Flow Meter Sizing
Seawater desalination skids usually run reverse osmosis membranes at 55 to 70 bar. Feed water conductivity in the Gulf region is often 45,000 to 55,000 µS/cm. That makes electromagnetic flow meters a strong fit. We supply DN40 to DN200 electromagnetic flow meters with PTFE lining and ground electrodes for seawater feed, brine reject, and backwash lines.
For brine reject flow, pressure is close to membrane feed pressure. Specify PN63 or PN100 flanges. For permeate water, pressure is low and the water is low conductivity. A battery powered electromagnetic flow meter may not work well if conductivity is below 20 µS/cm. Use a clamp on ultrasonic flow meter or a Coriolis mass flow meter for permeate lines.
In practice, most desalination skid builders in the Middle East order electromagnetic flow meters for feed and brine lines, then add a low cost turbine or oval gear flow meter for cleaning chemical injection. If you need totalized flow and batch control, an oval gear flow meter works well for chemical dosing pumps.
For seawater flow
_600x400.jpg)
Sensor Type and Signal Output
Most skid panels need a 4-20 mA HART signal or a pulse output. Silver Instruments electromagnetic flow meters can ship with 4-20 mA HART, RS485 Modbus, or pulse. For high pressure water meters on remote skids, we recommend the HART version because the signal can travel long cable runs without noise.
Temperature matters on desalination skids in Saudi Arabia and Oman. Skid surface temperatures can reach 60 °C, and seawater feed can reach 35 °C in summer. Specify PTFE lining and EPDM gaskets for these conditions. For water jet cutting skids in Latin America, high humidity is common. Use IP67 or IP68 sensor housings so condensation does not damage the terminal block.
We do not recommend a standard plastic body flow meter for high pressure water lines. A painted carbon steel flanged flow meter with PTFE lining is a good balance for price and life.
Sizing Example for a Water Jet Skid
A customer in Mexico built a water jet cutting table with a 3.0 kW feed pump. The skid flow was 2.4 m³/h at 6 bar. We supplied a DN25 electromagnetic flow meter with PN16 flanges, PTFE lining, 316L electrodes, and 4-20 mA HART output. Accuracy was 0.5% of reading. The meter fit inside the skid footprint and did not need straight pipe length longer than the skid panel.
For a desalination skid in the UAE, the customer needed a brine reject meter for 45 m³/h at 62 bar. We supplied a DN100 electromagnetic flow meter with PN63 flanges and a 24 V DC power input. The sensor body was carbon steel with PTFE lining. The display was mounted on the skid door with a 10 m cable. This setup passed the local integrator check without any recalibration on site.
What to Send for a Quote
Send us your pressure (bar), temperature (°C), pipe size (DN), and flow range. Add water type if you can. For example, seawater, RO permeate, recycled cutting water, or chemical dosing. That detail helps us pick the right materials. We reply within one working day with a model number, price, and lead time.
Contact Silver Instruments at Tel: +86-25-68650347 or Whatsapp: +86-25-52155837. WeChat: +86 15365082610. You can also visit our website flow-meter.com.au for more product details.
FAQ
Q: Can a standard electromagnetic flow meter handle 100 bar water pressure?
Yes. Use a flanged electromagnetic flow meter with PN100 rating and PTFE lining. We supply this size for desalination brine lines and water jet boost circuits. Do not use sanitary clamp style sensors above PN16.
Q: What flow meter is best for water jet cutting skids?
An electromagnetic flow meter on the low pressure feed line is the most reliable choice if water conductivity is above 20 µS/cm. For pure water below 20 µS/cm, use a Coriolis mass flow meter or an ultrasonic flow meter.
Q: How do I size a seawater flow meter for a desalination skid?
Start with pipe size and flow range. A DN80 meter works for about 30 to 60 m³/h at 55 bar. A DN100 meter works for about 50 to 100 m³/h. Check velocity stays between 0.5 and 10 m/s.
Q: Do you supply ATEX or hazardous area flow meters for skid panels?
Yes. We can supply ATEX Zone 1 versions for electromagnetic and Coriolis flow meters. Tell us the gas group and temperature class in your quote request.
Q: What is the typical lead time for a high pressure water flow meter?
Stock sizes like DN25, DN50, DN80, and DN100 ship in 3 to 5 days. Special flange ratings like PN100 or ATEX versions usually ship in 2 to 3 weeks.
