Mag 6000 Flow Meter: Siemens Digital Signal Transmitter Specs
Quick Answer
The Siemens Mag 6000 is a digital transmitter built for electromagnetic flow meters. It provides 4-20 mA HART, pulse, and frequency outputs and works with sensor sizes from DN 15 up to DN 1200. Silver Automation Instruments supplies complete magmeter packages with this transmitter and supports customers across Southeast Asia, Oceania, the Middle East, Africa, and Latin America.
Key Transmitter Specifications and Real-World Use
The Mag 6000 transmitter can be wall-mounted or panel-mounted. It accepts flow signals from electromagnetic sensors and delivers stable outputs even with low conductivity fluids down to 5 micro S/cm. In practice, most engineers wire the 4-20 mA HART channel directly to their DCS or PLC. A dairy plant in New Zealand used it on a CIP return line where rinse water reached 85 degrees C. The transmitter held zero drift and kept totalizer accuracy within 0.2 percent.
Power options include 115 to 230 V AC and 24 V DC. The housing meets IP67, so outdoor washdown is not a problem. For hazardous areas you can specify the ATEX Zone 1 certified version. Digital signal processing inside the Mag 6000 filters out noise from slurries with up to 10 percent solids. A system integrator in Ghana paired the Mag 6000 with a DN 200 sensor on a gold tailings line and recorded less than 0.3 percent measurement error after two years.
Silver Automation Instruments keeps the Mag 6000 in stock and matches it with our own magmeter sensors or sensors you already have. We also help with liner and electrode selection. PTFE, hard rubber, PFA, Hastelloy, titanium, and tantalum are all available depending on your fluid. If you need a direct replacement for an older transmitter, we can check the coil resistance and electrode input range and confirm compatibility before you order.
Quick Technical Highlights
Outputs: 4-20 mA, pulse, frequency, and HART protocol. Display: backlit LCD with three lines for flow rate, totalizer, and diagnostic codes. Accuracy: plus or minus 0.2 percent of rate with a matched sensor. Repeatability: plus or minus 0.05 percent. Ambient temperature range: minus 20 to 60 degrees C. Optional MODBUS RTU module via RS485 is available. All parameters can be set from the front keypad or via HART handheld communicator. No laptop is needed in the field.
Installation and On-Site Experience
Place the Mag 60
Because the Mag 6000 has a built-in data logger, you can extract flow history via HART or the PC software. A paint manufacturer in Thailand uses this feature monthly to cross-check solvent dosing logs against purchase orders and to justify batch records during ISO audits.
How to Get a Quote and Support
Send us a short message or email with your pipe size (DN), fluid name, conductivity, pressure (bar), temperature (degrees C), and required approvals. We will propose the right sensor, liner, electrode, and the Mag 6000 transmitter in one quote. Our email: [email protected]. Tel: +86-25-68650347. WhatsApp: +86-25-52155837. WeChat: +86 15365082610. We ship to Australia, Chile, Saudi Arabia, Vietnam, Nigeria, and over 30 other countries. You will receive a fixed price and lead time within one working day, often just a few hours.
FAQ: Mag 6000 Transmitter Common Questions
Can the Mag 6000 work with a sensor from another brand? It can, if the sensor coil resistance and electrode signal levels fall within the transmitter input range. Send us your sensor model and we will confirm.
What is the minimum fluid conductivity? 5 micro S/cm. Demineralized water and ultrapure water are below this limit without a special preamplifier. For pure water applications we offer alternative ultrasonic or Coriolis solutions.
Does it support Modbus communication? Yes, with an optional RS485 module running MODBUS RTU. Please specify this module when you request a quote.
Can it be used in hazardous areas? Yes, the ATEX Zone 1 certified variant is available. Share your zone classification and gas group with us when ordering.
What warranty does Silver Automation Instruments provide? 12 months standard warranty on all new Mag 6000 transmitters. We also offer an extended 24-month warranty option.
We hold stock of Mag 6000 transmitters for fast dispatch. For urgent on-site failures, ask our team about express air freight to your plant.
