Meter In and Meter Out Flow Control: Hydraulic Valve Direct Speed Tuning
Quick Answer: Meter-in and meter-out flow control circuits use valves to set cylinder speed. Direct speed tuning with a high-accuracy flow meter provides a real-time flow signal that replaces manual valve trimming. Silver Automation Instruments supplies oval gear flow meters and Coriolis mass flow meters that measure hydraulic oil flow within ±0.5% of reading. The analog or pulse output feeds into a PLC or motion controller. This approach cuts speed variation to less than 0.5 mm/s repeatability on presses, lifts, and injection machines.
Here is the thing. Most hydraulic systems still adjust speed with a manual needle valve or a proportional valve. The operator reads a pressure gauge and guesses the flow. Oil viscosity changes with temperature. The load shifts on every cycle. Without a flow meter in the line, you do not know the actual oil volume moving to the cylinder. A flow meter takes the guesswork out.
In a meter-in circuit, a throttle valve restricts flow into the cylinder port. In a meter-out circuit, the valve restricts flow leaving the cylinder. Both methods control speed, but neither measures the real flow rate. A sudden load change makes the cylinder slow down or speed up because the valve setting is static. By installing a positive displacement flow meter, like an oval gear type, you get a direct flow reading in liters per minute. That signal can drive the valve or pump in a closed loop. We call this direct speed tuning.
Silver Instruments SIL-OG oval gear flow meters work on mineral oil, synthetic esters, and water glycol fluids. The flow range starts at 0.1 L/min for small DN4 units and goes up to 500 L/min on DN50. Standard pressure rating is up to 420 bar. The built-in transmitter gives a 4-20 mA HART output or a frequency/pulse signal. You can wire it straight to a Siemens S7-1200 PLC or a Rexroth motion controller. Because the oval gear meter counts discrete volumes, it ignores viscosity changes. Accuracy is ±0.5% of rate across a 10:1 turn-down. That means you set a target speed of 50 mm/s, the meter keeps the flow constant even if the oil heats from 30°C to 60°C.
Last year, a hydraulic press manufacturer in Vietnam contacted us. Their press closing speed varied from 80 to 95 mm/s because the meter-out throttle valve drifted with oil temperature. They installed our SIL-OG15 flow meter on the rod-side return line. The analog output went to a Delta DVP PLC. The PLC then controlled a proportional directional valve. The speed settled at 85 mm/s with a deviation under 0.3 mm/s. This cut reject parts caused by inconsistent forming pressure. They bought 12 more units for the next production line.
Direct speed tuning also works with Coriolis mass flow meters when you need mass flow in kg/min. Our SIL-CMF se
In practice, most engineers skip the flow meter because they think a pressure transducer is enough. But pressure does not equal flow. A blocked cylinder can show high pressure and zero flow. With a flow meter, you catch conditions like a stuck valve, broken seal, or pump wear immediately. You can log flow trends on a paperless recorder. Our SIL-Recorder with 4-20 mA inputs logs flow, pressure, and temperature on one trend. That is useful for predictive maintenance in hydraulic power units.
If you want to move from manual valve speed setting to direct speed tuning, send us the following data: hydraulic oil type and viscosity (cSt at 40°C), working pressure (bar), maximum flow rate (L/min), and pipe size (DN). We will propose a ready-to-install flow meter with the right process connection (BSPP, SAE, or flanged). You will receive a detailed datasheet and a price quote within one working day. Email: [email protected], Tel: +86-25-68650347, Whatsapp: +86-25-52155837, WeChat: +86 15365082610. See more flow meter options at flow-meter.com.au.
FAQ on Meter-In/Meter-Out Flow Control and Direct Speed Tuning
Q1: What is the difference between meter-in and meter-out speed control?
A1: Meter-in restricts flow into the cylinder. Meter-out restricts flow leaving the cylinder. Both are open-loop unless a flow meter closes the loop.
Q2: Can a turbine flow meter work for direct speed tuning on hydraulic oil?
A2: Turbine meters need clean, low-viscosity fluid. Hydraulic oil viscosity and contamination often cause bearing wear. We recommend oval gear positive displacement meters for reliable readings.
Q3: How fast can the flow meter signal update the valve?
A3: Our oval gear meters output a 0-5 V pulse or 4-20 mA signal with a response time under 10 ms. Combined with a fast servo valve, you can correct speed within one PLC scan cycle.
Q4: What if my system already has a proportional valve with integrated pressure compensation?
A4: Pressure-compensated valves maintain constant flow regardless of load, but they do not measure actual flow. Adding a flow meter confirms the actual speed and detects internal leakage or drift over time.
Q5: How do I request a quotation for a hydraulic flow meter?
A5: Send us an email with your fluid type, pressure, temperature, flow range, and connection size. Our team will send a quotation, outline drawing, and installation note within 24 hours.
